序號 | 型號 | 負荷能力 | 臺面尺寸 | 閉合高度 | 升降行程 | 最高高度 | 電機功率 | 電源電壓 |
T | L長×W寬(MM) | (MM) | (MM) | (MM) | kw | V | ||
固定式液壓升降臺(單叉) | ||||||||
1 | SJG0.3-0.5 | 0.3 | 900*350 | 200 | 500 | 700 | 0.75 | 380v/50hz |
2 | SJG0.5-0.5 | 0.5 | 900*380 | 200 | 500 | 700 | 1.1 | 380v/50hz |
3 | SJG1-0.97 | 1 | 1500*1000 | 230 | 970 | 1200 | 1.5 | 380v/50hz |
4 | SJG1-1.5 | 1 | 2500*2000 | 340 | 1500 | 1840 | 2.2 | 380v/50hz |
5 | SJG1.5-1.2 | 1.5 | 2000*1500 | 350 | 1200 | 1550 | 2.2 | 380v/50hz |
6 | SJG2-1 | 2 | 1600*1000 | 300 | 1000 | 1300 | 2.2 | 380v/50hz |
7 | SJG2-1.6 | 2 | 2500*2000 | 360 | 1600 | 1960 | 3 | 380v/50hz |
8 | SJG3-1 | 3 | 1600*1200 | 360 | 1000 | 1360 | 3 | 380v/50hz |
9 | SJG4-1.2 | 4 | 2400*1200 | 400 | 1200 | 1600 | 4 | 380v/50hz |
10 | SJG5-1.5 | 5 | 2600*2000 | 480 | 1500 | 1980 | 4 | 380v/50hz |
11 | SJG6-1.2 | 6 | 2000*2000 | 480 | 1200 | 1680 | 4 | 380v/50hz |
12 | SJG8-1 | 8 | 1600*1600 | 500 | 1000 | 1500 | 4 | 380v/50hz |
13 | SJG10-1.6 | 10 | 3500*2200 | 680 | 1600 | 2280 | 5.5 | 380v/50hz |
14 | SJG15-1.6 | 15 | 3500*2200 | 780 | 1600 | 2380 | 7.5 | 380v/50hz |
15 | SJG20-1.8 | 20 | 6000*2500 | 720 | 1800 | 2520 | 7.5 | 380v/50hz |
16 | SJG30-1.6 | 30 | 7000*3000 | 880 | 1600 | 2480 | 11 | 380v/50hz |
固定式液壓升降臺(雙叉) | ||||||||
17 | SJG1-2.2 | 1 | 1500*1000 | 400 | 2200 | 2600 | 2.2 | 380v/50hz |
18 | SJG2-1.9 | 2 | 1600*1200 | 480 | 1900 | 2380 | 3 | 380v/50hz |
19 | SJG3-1.8 | 3 | 1500*1500 | 520 | 1800 | 2320 | 4 | 380v/50hz |
20 | SJG3-2.3 | 3 | 2000*1800 | 550 | 2300 | 2850 | 4 | 380v/50hz |
21 | SJG10-4 | 10 | 3500*3000 | 1100 | 4000 | 5100 | 7.5 | 380v/50hz |
22 | SJG0.8-1.2 | 800 | 1200*1000 | 300 | 1200 | 1500 | 1.1 | 380v/50hz |
23 | SJG1-1.7 | 1000 | 1500*1000 | 350 | 1700 | 2050 | 1.5 | 380v/50hz |
24 | SJG2-1.2 | 2000 | 1500*1000 | 335 | 1200 | 1535 | 3 | 380v/50hz |
25 | SJG2-2.4 | 2000 | 2000*1500 | 500 | 2400 | 2900 | 3 | 380v/50hz |
26 | SJG1-1.6 | 1000 | 1500*1200 | 400 | 1600 | 2000 | 1.5 | 380v/50hz |
27 | SJG2-2 | 2000 | 2200*1200 | 620 | 2000 | 2620 | 3 | 380v/50hz |
28 | SJG2-1.2 | 2000 | 1600*1600 | 415 | 1200 | 1615 | 3 | 380v/50hz |
29 | SJG4-2.3 | 4000 | 2200*1000 | 660 | 2300 | 2960 | 5.5 | 380v/50hz |
30 | SJG3-1.5 | 3000 | 1700*1000 | 460 | 1500 | 1960 | 4 | 380v/50h |
